• Read the safety instructions Safety First
• Ensure your mobile/tablet/pc is less than 5 years old and up to date
• You need Wi-Fi and a web browser installed, we recommend Brave or Chrome as the browser
• Setup the unit in the SHADE, it MUST be fully shaded
• Power up the unit with the USB cable and 5v USB power supply, in the shaded location where you want to use it
• Connect your phone/tablet to the Chrony Wi-Fi Network
• Open your web browser & access the NateChrony ExtremeBallistic page via one of the below methods:

  http://192.168.4.1
  http://xballistic
  http://xballistic.local

  NOTE: If it is in ballistic mode, the address will be http://192.168.5.1

• Go to the Setup page
• Adjust the Sensitivity to the required value based on the projectile you are using
• It will reboot and you will be good to go
• If you get detection errors, reduce the sensitivity value (make it more sensitive)
• If you are getting sensor errors without a shot (false triggers), increase the sensitivity value (make it less sensitive)

Setup Video

Follow these steps to be able to test and get familiar with your NateChrony without having to mount it or fire a single shot!

• Read the safety instructions Safety First
• Ensure your mobile/tablet/pc is less than 5 years old and up to date
• You need Wi-Fi and a web browser installed, we recommend Brave or Chrome as the browser
• Power up your NateChrony with a USB cable and power supply
• Connect your mobile/tablet/laptop to the Chrony WiFi network
• Open your browser & access the NateChrony page via one of the below methods:

  http://192.168.4.1
  http://natechrony
  http://natechrony.local
  http://steadyshot
  http://steadyshot.local


SteadyShot NOTE: If it is in ballistic mode, the address will be http://192.168.5.1

• Drop the test pellet through the NateChrony, its important to use the test pellet or something 7mm/30cal to ensure it triggers both sensors
• It should read approximately 4fps, repeat the drop 2-3 times
• You should see an alignment error, this is expected
• If the pellet doesnt pass through quickly (>0.5fps), the chrony may detect a sensor issue & reset - make sure its dropped vertically and doesnt rattle about inside

Setup Video

Follow these steps to setup and test your SmartTarget:

• Read the safety instructions Safety First
• Ensure your mobile/tablet/pc is less than 5 years old and up to date
• You need Wi-Fi and a web browser installed, we recommend Brave or Chrome as the browser
• Ensure the NateChrony SmartTarget cannot be struck by a projectile
• Mount the SmartTarget to rear of the target surface
• Mount the required accessories (if purchased) - antenna, external LEDs
• The connection order of the LEDs is specified in the setup screen:
  4/5 LEDs: bottom, (center), right, top, left
  10 LEDs: 1&2 = eyes, 3-10 = antlers/sparkle

• Setup the target into its location
• Power up the unit, ensuring the power supply cannot be struck by a projectile
• Connect your mobile/tablet/laptop to the SmartTarget WiFi network
• Open your browser & access the NateChrony page via one of the below methods:

  http://192.168.4.1
  http://smarttarget
  http://smarttarget.local
  Use your camera with this QR Code:

• Tap the target surface to ensure you get a successful hit detection
• Perform the calibration process

Setup Video
